What is an Electric Position Indicator for Pneumatic Valves?
What is an Electric Position Indicator for Pneumatic Valves?
The electric position indicator with 2 microswitches monitors the OPEN & CLOSED positions of the piloted angle seat valves of the 845xx and 847xx series.
How does it work?
The limit switches wired in series with a terminal block are screwed onto supports and can be adjusted independently of each other with threaded spindles. Switches, operating mechanism and terminal block are protected by a transparent cover on the plastic bottom section of the case, which can be turned to any direction.
This position indicator can also be retrofitted to unmodified piloted angle seat valves of the above-mentioned series. The operating spindle is connected to the valve spindle frictionally and axially without any slack.
This indicator can be ordered for retrofitting under Catalogue number 1257000.
What are the benefits of Electric Position Indicators for Pneumatic Valves?
Reproducible switching point accuracy
Long mechanical and electrical service life
Readily retrofitted
Simple, accurate adjustment of switching point
With LED indicator
